Kyosho Fazer Mk2 FZ02L

Stock is as the vehicle ships. Calculated is worked from the stock figures on this page rather than stored beside them, so the two cannot drift apart. Not applicable means the vehicle does not come with it, like the motor on a roller or the tires on a race kit, or does not have one, like a KV rating on a brushed motor.

How these numbers were settled

The long-wheelbase FZ02L (274mm) shares the FZ02's 6.54:1 but rolls on smaller 64mm tires rather than the FZ02's 66mm, so it is listed separately.

• Kyosho's Technical Data gives 'Gear Ratio 6.54:1' and 'Tires (F/R) 64x27.7mm'.
• The figures are identical across the FZ02L bodies Kyosho sells; 34434T1 is the representative SKU and 34475T1 prints the same block.
• Pinion 32T, spur 68T and the 6.54:1 total are all on Kyosho's own spec block; 6.54 / (68/32) = 3.077 is the ratio after the spur.
• The fitted G14L is a 550-size 14T brushed motor, rated by turn count rather than KV.
• The cell count is from the manual's required-battery page, which lists a 2S LiPo or a 6-cell NiMH; Kyosho prints no maximum.

Sources

• 34434t1rc.kyosho.com (opens in a new tab)
• 34475t1rc.kyosho.com (opens in a new tab)
• 1-10-scale-radio-controlled…kyoshoamerica.com (opens in a new tab)
• fazer-sprc.kyosho.com (opens in a new tab)

Every figure on this page traces to one of these. Where they disagreed, the note above says which was used and why.
