VehiclesYokomo YD-4 MR
Specifications
Last modified
| Spec | Value | Basis |
|---|---|---|
| Drivetrain | ||
| Pinion | Not applicable | |
| Spur | Not applicable | |
| Transmission & axle | 2.35:1Stock | Stock |
| Final drive | Not applicable | |
| Wheels & tires | ||
| Tire diameter | Not applicable | |
| Power | ||
| Motor | Not applicable | |
| Battery | Up to 2SLiPoStock | Stock |
| Performance | ||
| Theoretical top speed | Not applicable | |
| Vehicle | ||
| Part number | DP-YD4MR | |
| Scale | 1/10 | |
Stock is as the vehicle ships. Calculated is worked from the stock figures on this page rather than stored beside them, so the two cannot drift apart. Not applicable means the vehicle does not come with it, like the motor on a roller or the tires on a race kit, or does not have one, like a KV rating on a brushed motor.
How these numbers were settled
Shaft-drive 4WD counter-steer, rear-midship motor, front one-way and a solid rear axle.
- Yokomo publishes the second reduction as 2.35:1 and the counter-steer as FCD x1.3 rear speed-up.
- Its FCD compliance table lists the other gears as x1.5, x1.8 and x2.0 for the Drift Package, so 1.3 is the kit figure rather than the only one available.
- Note the YD-2 writes its reduction as 1:2.6 and the YD-4 as 2.35:1; the order is flipped but both mean the transmission constant.
Sources
Every figure on this page traces to one of these. Where they disagreed, the note above says which was used and why.
